ARES® stainless steel actuated angle seat valve 1452 normally open BSP
The ARES Type 1452 is a stainless steel valve, normally open (NO), for all compatible media.
Documentation
Certificate of Conformity
pdf - 192.3 ko
Details
Option certificate 3.1 | Yes |
---|---|
Maximum delta P (bar) | 16 |
ATEX compatible | No |
Face to Face (mm) | 85.0 |
Gasket | PTFE |
Kv (m³/h) | 5.70 |
Body material | Stainless steel CF8M (1.4408) |
Bearing | PTFE |
Position | Normally open |
PS (bar) | 25 |
Connections | BSP FF |
TS max (°C) | 180 |
TS min (°C) | -10 |
Flow entry | Below the seat |
Solenoid pilot valve ways | 2/2 |
Warranty period | 1 year |
CE | Excluded (Article 4. §3) |
